TimePicker

The <TimePicker> component allows users to select a time (with the hour and minute) from the given range.

NOTE

This component is supported since API version 8. Updates will be marked with a superscript to indicate their earliest API version.

Child Components

Not supported

APIs

TimePicker(options?: {selected?: Date})

Creates a time picker, which is in 24-hour format by default.

Parameters

Name	Type	Mandatory	Description
selected	Date	No	Time of the selected item. Default value: current system time Since API version 10, this parameter supports $$ for two-way binding of variables.

Attributes

In addition to the universal attributes, the following attributes are supported.

Name	Type	Description
useMilitaryTime	boolean	Whether the display time is in 24-hour format. Default value: false NOTE When in the 12-hour format, the AM/PM zone does not change depending on the hour portion.
disappearTextStyle¹⁰⁺	PickerTextStyle	Font color, font size, and font width for the top and bottom items. Default value: { color: ‘#ff182431’, font: { size: ‘14fp’, weight: FontWeight.Regular } }
textStyle¹⁰⁺	PickerTextStyle	Font color, font size, and font width of all items except the top, bottom, and selected items. Default value: { color: ‘#ff182431’, font: { size: ‘16fp’, weight: FontWeight.Regular } }
selectedTextStyle¹⁰⁺	PickerTextStyle	Font color, font size, and font width of the selected item. Default value: { color: ‘#ff007dff’, font: { size: ‘20vp’, weight: FontWeight.Medium } }

Events

In addition to the universal events, the following events are supported.

Name	Description
onChange(callback: (value: TimePickerResult ) => void)	Triggered when a time is selected.

TimePickerResult

Describes a time in 24-hour format.

Name	Type	Description
hour	number	Hour portion of the selected time. Value range: [0-23]
minute	number	Minute portion of the selected time. Value range: [0-59]

Example

// xxx.ets
@Entry
@Component
struct TimePickerExample {
  @State isMilitaryTime: boolean = false
  private selectedTime: Date = new Date('2022-07-22T08:00:00')

  build() {
    Column() {
      Button ('Switch Time Format')
        .margin({ top: 30 })
        .onClick(() => {
          this.isMilitaryTime = !this.isMilitaryTime
        })
      TimePicker({
        selected: this.selectedTime,
      })
        .useMilitaryTime(this.isMilitaryTime)
        .onChange((value: TimePickerResult) => {
          if(value.hour) {
            this.selectedTime.setHours(value.hour, value.minute)
            console.info('select current date is: ' + JSON.stringify(value))
          }
        })
        .disappearTextStyle({color: Color.Red, font: {size: 15, weight: FontWeight.Lighter}})
        .textStyle({color: Color.Black, font: {size: 20, weight: FontWeight.Normal}})
        .selectedTextStyle({color: Color.Blue, font: {size: 30, weight: FontWeight.Bolder}})
    }.width('100%')
  }
}

timePicker
