Navigator

The <Navigator> component provides redirection.

NOTE

This component is supported since API version 7. Updates will be marked with a superscript to indicate their earliest API version.

Child Components

Supported

APIs

Navigator(value?: {target: string, type?: NavigationType})

Parameters

Name Type Mandatory Description
target string Yes Path of the target page to be redirected to.
type NavigationType No Navigation type.
Default value: NavigationType.Push

NavigationType

Name Description
Push Navigates to the specified page in the application.
Replace Replaces the current page with another one in the application and destroys the current page.
Back Returns to the specified page. If the specified page does not exist in the stack, no response is returned. If no page is specified, the previous page is returned to.

Attributes

Name Parameter Description
active boolean Whether the <Navigator> component is activated. If the component is activated, the corresponding navigation takes effect.
params object Data that needs to be passed to the target page during redirection. You can use router.getParams() to obtain the data on the target page.
target string Path of the target page to be redirected to. The target page must be added to the main_pages.json file.
type NavigationType Navigation type.
Default value: NavigationType.Push

Example

// Navigator.ets
@Entry
@Component
struct NavigatorExample {
  @State active: boolean = false
  @State name: NameObject = { name: 'news' }

  build() {
    Flex({ direction: FlexDirection.Column, alignItems: ItemAlign.Start, justifyContent: FlexAlign.SpaceBetween }) {
      Navigator({ target: 'pages/container/navigator/Detail', type: NavigationType.Push }) {
        Text('Go to ' + this.name.name + ' page')
          .width('100%').textAlign(TextAlign.Center)
      }.params(new TextObject(this.name)) // Pass parameters to the Detail page.

      Navigator() {
        Text('Back to previous page').width('100%').textAlign(TextAlign.Center)
      }.active(this.active)
      .onClick(() => {
        this.active = true
      })
    }.height(150).width(350).padding(35)
  }
}

interface NameObject {
  name: string;
}

class TextObject {
  text: NameObject;

  constructor(text: NameObject) {
    this.text = text;
  }
}
// Detail.ets
import router from '@ohos.router'

@Entry
@Component
struct DetailExample {
  // Receive the input parameters of Navigator.ets.
  params: Record<string, NameObject> = router.getParams() as Record<string, NameObject>
  @State name: NameObject = this.params.text

  build() {
    Flex({ direction: FlexDirection.Column, alignItems: ItemAlign.Start, justifyContent: FlexAlign.SpaceBetween }) {
      Navigator({ target: 'pages/container/navigator/Back', type: NavigationType.Push }) {
        Text('Go to back page').width('100%').height(20)
      }

      Text('This is ' + this.name.name + ' page')
        .width('100%').textAlign(TextAlign.Center)
    }
    .width('100%').height(200).padding({ left: 35, right: 35, top: 35 })
  }
}

interface NameObject {
  name: string;
}
// Back.ets
@Entry
@Component
struct BackExample {
  build() {
    Column() {
      Navigator({ target: 'pages/container/navigator/Navigator', type: NavigationType.Back }) {
        Text('Return to Navigator Page').width('100%').textAlign(TextAlign.Center)
      }
    }.width('100%').height(200).padding({ left: 35, right: 35, top: 35 })
  }
}

en-us_image_0000001212058486
