Class (UIObserver)
Provides APIs for listening for UI component behavior changes.
NOTE
The initial APIs of this module are supported since API version 10. Newly added APIs will be marked with a superscript to indicate their earliest API version.
The initial APIs of this class are supported since API version 11.
In the following API examples, you must first use getUIObserver() in UIContext to obtain a UIObserver instance, and then call the APIs using the obtained instance.
UIObserver can only listen for relevant information within the current process and does not support obtaining information in cross-process scenarios such as UIExtensionComponent.
on('navDestinationUpdate')11+
on(type: 'navDestinationUpdate', callback: Callback<observer.NavDestinationInfo>): void
Listens for NavDestination component state changes.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationUpdate', which indicates NavDestination component state changes. |
| callback | Callback<observer.NavDestinationInfo> | Yes | Callback used to return the current NavDestination component state. |
Example
// Index.ets
// Example usage of uiObserver.on('navDestinationUpdate', callback)
// uiObserver.off('navDestinationUpdate', callback)
@Component
struct PageOne {
build() {
NavDestination() {
Text("pageOne")
}.title("pageOne")
}
}
@Entry
@Component
struct Index {
private stack: NavPathStack = new NavPathStack();
@Builder
PageBuilder(name: string) {
PageOne()
}
aboutToAppear() {
// Add event listeners.
this.getUIContext().getUIObserver().on('navDestinationUpdate', (info) => {
console.info('NavDestination state update', JSON.stringify(info));
});
}
aboutToDisappear() {
// Unregister the listener. Omitting the callback parameter removes all registered listeners.
this.getUIContext().getUIObserver().off('navDestinationUpdate');
}
build() {
Column() {
Navigation(this.stack) {
Button("push").onClick(() => {
// Push the PageOne NavDestination onto the navigation stack.
this.stack.pushPath({ name: "pageOne" });
})
}
.title("Navigation")
.navDestination(this.PageBuilder)
}
.width('100%')
.height('100%')
}
}
off('navDestinationUpdate')11+
off(type: 'navDestinationUpdate', callback?: Callback<observer.NavDestinationInfo>): void
Unregisters the listener for NavDestination component state changes.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationUpdate', which indicates NavDestination component state changes. |
| callback | Callback<observer.NavDestinationInfo> | No | Target listener to unregister. If this parameter is not provided, all Navigation listeners are unregistered. |
Example
See the example for on('navDestinationUpdate').
on('navDestinationUpdate')11+
on(type: 'navDestinationUpdate', options: { navigationId: ResourceStr }, callback: Callback<observer.NavDestinationInfo>): void
Listens for NavDestination component state changes via the Navigation component ID.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationUpdate', which indicates NavDestination component state changes. |
| options | { navigationId: ResourceStr } | Yes | ID of the target Navigation component. |
| callback | Callback<observer.NavDestinationInfo> | Yes | Callback used to return the current NavDestination component state. |
Example
// Index.ets
// Example usage of uiObserver.on('navDestinationUpdate', options, callback)
// uiObserver.off('navDestinationUpdate', options, callback)
@Component
struct PageOne {
build() {
NavDestination() {
Text("pageOne")
}.title("pageOne")
}
}
@Entry
@Component
struct Index {
private stack: NavPathStack = new NavPathStack();
@Builder
PageBuilder(name: string) {
PageOne()
}
aboutToAppear() {
// Register a listener with the specified Navigation component ID.
this.getUIContext().getUIObserver().on('navDestinationUpdate', { navigationId: "testId" }, (info) => {
console.info('NavDestination state update', JSON.stringify(info));
});
}
aboutToDisappear() {
// Unregister the listener. Omitting the callback parameter removes all registered listeners.
this.getUIContext().getUIObserver().off('navDestinationUpdate', { navigationId: "testId" });
}
build() {
Column() {
Navigation(this.stack) {
Button("push").onClick(() => {
// Push the PageOne NavDestination onto the navigation stack.
this.stack.pushPath({ name: "pageOne" });
})
}
.id("testId")
.title("Navigation")
.navDestination(this.PageBuilder)
}
.width('100%')
.height('100%')
}
}
off('navDestinationUpdate')11+
off(type: 'navDestinationUpdate', options: { navigationId: ResourceStr }, callback?: Callback<observer.NavDestinationInfo>): void
Unregisters the listener for NavDestination component state changes via the Navigation component ID.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationUpdate', which indicates NavDestination component state changes. |
| options | { navigationId: ResourceStr } | Yes | ID of the target Navigation component. |
| callback | Callback<observer.NavDestinationInfo> | No | Target listener to unregister. If this parameter is not provided, all listeners for the target Navigation are unregistered. |
Example
See the example for on('navDestinationUpdate').
on('navDestinationUpdateByUniqueId')20+
on(type: 'navDestinationUpdateByUniqueId', navigationUniqueId: number, callback: Callback<observer.NavDestinationInfo>): void
Listens for NavDestination component state changes using the Navigation component's uniqueId. Obtain the uniqueId via queryNavigationInfo.
Atomic service API: This API can be used in atomic services since API version 20.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationUpdateByUniqueId', which indicates NavDestination component state changes. |
| navigationUniqueId | number | Yes | Unique ID of the target Navigation component, which can be obtained using queryNavigationInfo. |
| callback | Callback<observer.NavDestinationInfo> | Yes | Callback used to return the current NavDestination component state. |
Example
This example demonstrates how to trigger NavDestination component state changes using the Navigation component's uniqueId.
// Index.ets
// Example usage of on('navDestinationUpdateByUniqueId', navigationUniqueId, callback)
// off('navDestinationUpdateByUniqueId', navigationUniqueId, callback)
@Component
struct PageOne {
private text = '';
private uniqueid = -1;
aboutToAppear() {
// Obtain the uniqueId of the target Navigation component.
let navigationUniqueId = this.queryNavigationInfo()?.uniqueId;
if (navigationUniqueId) {
this.uniqueid = navigationUniqueId.valueOf();
}
this.text = JSON.stringify(this.uniqueid);
// Register a listener with the specified Navigation component uniqueId.
this.getUIContext().getUIObserver().on('navDestinationUpdateByUniqueId', this.uniqueid, (info) => {
console.info('NavDestination state update navigationId', JSON.stringify(info));
});
}
aboutToDisappear() {
// Unregister the listener. Omitting the callback parameter removes all registered listeners.
this.getUIContext().getUIObserver().off('navDestinationUpdateByUniqueId', this.uniqueid);
}
build() {
NavDestination() {
Text("pageOne")
Text('navigationUniqueId: ' + this.text)
.width('80%')
.height(50)
.margin(50)
.fontSize(20)
}.title("pageOne")
}
}
@Entry
@Component
struct Index {
private stack: NavPathStack = new NavPathStack();
@Builder
PageBuilder(name: string) {
PageOne()
}
build() {
Column() {
Navigation(this.stack) {
Button("push").onClick(() => {
// Push the PageOne NavDestination onto the navigation stack.
this.stack.pushPath({ name: "pageOne" });
})
}
.id("testId")
.title("Navigation")
.navDestination(this.PageBuilder)
}
.width('100%')
.height('100%')
}
}
off('navDestinationUpdateByUniqueId')20+
off(type: 'navDestinationUpdateByUniqueId', navigationUniqueId: number, callback?: Callback<observer.NavDestinationInfo>): void
Unregisters the listener for NavDestination component changes via the Navigation component uniqueId.
Atomic service API: This API can be used in atomic services since API version 20.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationUpdateByUniqueId', which indicates NavDestination component state changes. |
| navigationUniqueId | number | Yes | Unique ID of the target Navigation component, which can be obtained using queryNavigationInfo. |
| callback | Callback<observer.NavDestinationInfo> | No | Target listener to unregister. If this parameter is not provided, all listeners for the target Navigation are unregistered. |
Example
See the example for on('navDestinationUpdateByUniqueId').
on('scrollEvent')12+
on(type: 'scrollEvent', callback: Callback<observer.ScrollEventInfo>): void
Listens for the start and end of scroll events of all scrollable components. Supported components include List, Grid, Scroll, WaterFlow, and ArcList.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'scrollEvent' indicates the start and end of a scroll event. |
| callback | Callback<observer.ScrollEventInfo> | Yes | Callback used to return the information about the scroll event. |
Example
// Index.ets
// Example usage of uiObserver.on('scrollEvent', callback)
// uiObserver.off('scrollEvent', callback)
// uiObserver.on('scrollEvent', options, callback)
// uiObserver.off('scrollEvent', options, callback)
import { UIObserver } from '@kit.ArkUI';
@Entry
@Component
struct Index {
scroller: Scroller = new Scroller();
observer: UIObserver = this.getUIContext().getUIObserver();
private arr: number[] = [0, 1, 2, 3, 4, 5, 6, 7];
build() {
Column() {
Column() {
Scroll(this.scroller) {
Column() {
ForEach(this.arr, (item: number) => {
Text(item.toString())
.width('90%')
.height(150)
.backgroundColor(0xFFFFFF)
.borderRadius(15)
.fontSize(16)
.textAlign(TextAlign.Center)
.margin({ top: 10 })
}, (item: string) => item)
}.width('100%')
}
.id('testId')
.height('80%')
}
.width('100%')
Row() {
Button('UIObserver on')
.onClick(() => {
// Add event listeners.
this.observer.on('scrollEvent', (info) => {
console.info('scrollEventInfo', JSON.stringify(info));
});
})
Button('UIObserver off')
.onClick(() => {
// Unregister the listener. Omitting the callback parameter removes all registered listeners.
this.observer.off('scrollEvent');
})
}
Row() {
Button('UIObserverWithId on')
.onClick(() => {
// Register a listener with the specified scrollable component ID.
this.observer.on('scrollEvent', { id: 'testId' }, (info) => {
console.info('scrollEventInfo', JSON.stringify(info));
});
})
Button('UIObserverWithId off')
.onClick(() => {
// Unregister the listener. Omitting the callback parameter removes all registered listeners.
this.observer.off('scrollEvent', { id: 'testId' });
})
}
}
.height('100%')
}
}
off('scrollEvent')12+
off(type: 'scrollEvent', callback?: Callback<observer.ScrollEventInfo>): void
Unregisters the listener for the start and end of scroll events of all scrollable components. Supported components include List, Grid, Scroll, WaterFlow, and ArcList.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'scrollEvent' indicates the start and end of a scroll event. |
| callback | Callback<observer.ScrollEventInfo> | No | Callback used to return the information about the scroll event. If no parameter is provided, all scroll event listeners are unregistered. |
Example
See the example for on('scrollEvent').
on('scrollEvent')12+
on(type: 'scrollEvent', options: observer.ObserverOptions, callback: Callback<observer.ScrollEventInfo>): void
Listens for the start and end of scroll events of a specific scrollable component identified by its ID. Supported components include List, Grid, Scroll, WaterFlow, and ArcList.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'scrollEvent' indicates the start and end of a scroll event. |
| options | observer.ObserverOptions | Yes | Observer options, including the ID of the target scrollable component. |
| callback | Callback<observer.ScrollEventInfo> | Yes | Callback used to return the information about the scroll event. |
Example
See the example for on('scrollEvent').
off('scrollEvent')12+
off(type: 'scrollEvent', options: observer.ObserverOptions, callback?: Callback<observer.ScrollEventInfo>): void
Unregisters the listener for the start and end of scroll events of a specific scrollable component identified by its ID. Supported components include List, Grid, Scroll, WaterFlow, and ArcList.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'scrollEvent' indicates the start and end of a scroll event. |
| options | observer.ObserverOptions | Yes | Observer options, including the ID of the target scrollable component. |
| callback | Callback<observer.ScrollEventInfo> | No | Callback used to return the information about the scroll event. If no parameter is provided, all scroll event listeners are unregistered. |
Example
See the example for on('scrollEvent').
on('routerPageUpdate')11+
on(type: 'routerPageUpdate', callback: Callback<observer.RouterPageInfo>): void
Listens for page state changes in the Router.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'routerPageUpdate', which indicates page state changes in the Router. |
| callback | Callback<observer.RouterPageInfo> | Yes | Callback used to return the current page state using a RouterPageInfo object. |
Example
// PageOne.ets
@Entry
@Component
struct PageOne {
build() {
Column() {
Text("pageOne")
}
}
}
// Index.ets
// Example usage of uiObserver.on('routerPageUpdate', callback)
// uiObserver.off('routerPageUpdate', callback)
@Entry
@Component
struct Index {
aboutToAppear() {
// Add event listeners.
this.getUIContext().getUIObserver().on('routerPageUpdate', (info) => {
console.info('router page update', JSON.stringify(info));
});
}
aboutToDisappear() {
// Unregister the listener. Omitting the callback parameter removes all registered listeners.
this.getUIContext().getUIObserver().off('routerPageUpdate');
}
build() {
Column() {
Button("pushUrl").onClick(() => {
// Navigate to PageOne.ets using router.
this.getUIContext().getRouter().pushUrl({ url: 'pages/PageOne' })
})
}
.width('100%')
.height('100%')
}
}
off('routerPageUpdate')11+
off(type: 'routerPageUpdate', callback?: Callback<observer.RouterPageInfo>): void
Unregisters the listener for page state changes in the Router.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'routerPageUpdate', which indicates page state changes in the Router. |
| callback | Callback<observer.RouterPageInfo> | No | Target listener to unregister. If this parameter is omitted, all page state change listeners for the Router are removed. |
Example
See the example for on('routerPageUpdate').
on('densityUpdate')12+
on(type: 'densityUpdate', callback: Callback<observer.DensityInfo>): void
Listens for screen pixel density changes.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'densityUpdate' indicates the pixel density changes of the screen. |
| callback | Callback<observer.DensityInfo> | Yes | Callback used to return the updated screen pixel density using a DensityInfo object. |
Example
// Index.ets
// Example usage of uiObserver.on('densityUpdate', callback)
// uiObserver.off('densityUpdate', callback)
import { uiObserver } from '@kit.ArkUI';
@Entry
@Component
struct Index {
@State density: number = 0;
@State message: string = 'Listener not registered';
// Define callbacks for event listeners.
densityUpdateCallback = (info: uiObserver.DensityInfo) => {
this.density = info.density;
this.message = 'DPI after change:' + this.density.toString();
}
build() {
Column() {
Text(this.message)
.fontSize(24)
.fontWeight(FontWeight.Bold)
Button ('Subscribe to Screen Pixel Density Changes')
.margin({ bottom: 10 })
.onClick(() => {
this.message = 'Listener registered';
// Add event listeners.
this.getUIContext().getUIObserver().on('densityUpdate', this.densityUpdateCallback);
})
Button ('Unsubscribe from Screen Pixel Density Changes')
.onClick(() => {
this.message = 'Listener not registered';
// Remove event listeners.
this.getUIContext().getUIObserver().off('densityUpdate', this.densityUpdateCallback);
})
}
}
}
off('densityUpdate')12+
off(type: 'densityUpdate', callback?: Callback<observer.DensityInfo>): void
Unregisters the listener for screen pixel density changes.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'densityUpdate' indicates the pixel density changes of the screen. |
| callback | Callback<observer.DensityInfo> | No | Target listener to unregister. If no parameter is provided, all screen pixel density change listeners for the current UIContext are removed. |
Example
See the example for on('densityUpdate').
on('willDraw')12+
on(type: 'willDraw', callback: Callback<void>): void
Listens for drawing instruction dispatch in each frame.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event event. The value 'willDraw' indicates whether drawing is about to occur. |
| callback | Callback<void> | Yes | Callback used to return the result. |
Example
// Index.ets
// Example usage of uiObserver.on('willDraw', callback)
// uiObserver.off('willDraw', callback)
@Entry
@Component
struct Index {
// Define callbacks for event listeners.
willDrawCallback = () => {
console.info("willDraw instruction dispatched.");
}
build() {
Column() {
Button('Listen for Drawing Instruction Dispatch')
.margin({ bottom: 10 })
.onClick(() => {
// Add event listeners.
this.getUIContext().getUIObserver().on('willDraw', this.willDrawCallback);
})
Button('Unregister Drawing Instruction Dispatch Listener')
.onClick(() => {
// Remove event listeners.
this.getUIContext().getUIObserver().off('willDraw', this.willDrawCallback);
})
}
}
}
off('willDraw')12+
off(type: 'willDraw', callback?: Callback<void>): void
Unregisters the listener for drawing instruction dispatch in each frame.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event event. The value 'willDraw' indicates whether drawing is about to occur. |
| callback | Callback<void> | No | Target listener to unregister. If no parameter is provided, all drawing instruction dispatch listeners are unregistered. |
Example
See the example for on('willDraw').
on('didLayout')12+
on(type: 'didLayout', callback: Callback<void>): void
Listens for layout completion status in each frame.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'didLayout' indicates whether the layout has been completed. |
| callback | Callback<void> | Yes | Callback used to return the result. |
Example
// Index.ets
// Example usage of uiObserver.on('didLayout', callback)
// uiObserver.off('didLayout', callback)
@Entry
@Component
struct Index {
// Define callbacks for event listeners.
didLayoutCallback = () => {
console.info("Layout completed.");
}
build() {
Column() {
Button('Listen for Layout Completion')
.margin({ bottom: 10 })
.onClick(() => {
// Add event listeners.
this.getUIContext().getUIObserver().on('didLayout', this.didLayoutCallback);
})
Button('Unregister Layout Completion Listener')
.onClick(() => {
// Remove event listeners.
this.getUIContext().getUIObserver().off('didLayout', this.didLayoutCallback);
})
}
}
}
off('didLayout')12+
off(type: 'didLayout', callback?: Callback<void>): void
Unregisters the listener for layout completion status in each frame.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'didLayout' indicates whether the layout has been completed. |
| callback | Callback<void> | No | Target listener to unregister. If no parameter is provided, all layout completion listeners are unregistered. |
Example
See the example for on('didLayout').
on('navDestinationSwitch')12+
on(type: 'navDestinationSwitch', callback: Callback<observer.NavDestinationSwitchInfo>): void
Listens for Navigation page switch events.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationSwitch', which indicates Navigation page switch events. |
| callback | Callback<observer.NavDestinationSwitchInfo> | Yes | Callback used to return the page switch event information using a NavDestinationSwitchInfo object. |
Example
// Index.ets
// Example usage of UIObserver.on('navDestinationSwitch', callback)
// UIObserver.off('navDestinationSwitch', callback)
import { uiObserver } from '@kit.ArkUI';
@Component
struct PageOne {
build() {
NavDestination() {
Text("pageOne")
}.title("pageOne")
}
}
// Define callbacks for event listeners.
function callbackFunc(info: uiObserver.NavDestinationSwitchInfo) {
console.info(`testTag navDestinationSwitch from: ${JSON.stringify(info.from)} to: ${JSON.stringify(info.to)}`);
}
@Entry
@Component
struct Index {
private stack: NavPathStack = new NavPathStack();
@Builder
PageBuilder(name: string) {
PageOne()
}
aboutToAppear() {
let obs = this.getUIContext().getUIObserver();
// Add event listeners.
obs.on('navDestinationSwitch', callbackFunc);
}
aboutToDisappear() {
let obs = this.getUIContext().getUIObserver();
// Remove event listeners.
obs.off('navDestinationSwitch', callbackFunc);
}
build() {
Column() {
Navigation(this.stack) {
Button("push").onClick(() => {
// Push the PageOne NavDestination onto the navigation stack.
this.stack.pushPath({ name: "pageOne" });
})
}
.title("Navigation")
.navDestination(this.PageBuilder)
}
.width('100%')
.height('100%')
}
}
off('navDestinationSwitch')12+
off(type: 'navDestinationSwitch', callback?: Callback<observer.NavDestinationSwitchInfo>): void
Removes the listener for Navigation page switch events.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationSwitch', which indicates Navigation page switch events. |
| callback | Callback<observer.NavDestinationSwitchInfo> | No | Target listener to unregister. If no parameter is provided, all Navigation listeners are unregistered. |
Example
See the example for on('navDestinationSwitch').
on('navDestinationSwitch')12+
on(type: 'navDestinationSwitch', observerOptions: observer.NavDestinationSwitchObserverOptions, callback: Callback<observer.NavDestinationSwitchInfo>): void
Listens for Navigation page switch events with configurable observer options.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationSwitch', which indicates Navigation page switch events. |
| observerOptions | observer.NavDestinationSwitchObserverOptions | Yes | Observer configuration options. |
| callback | Callback<observer.NavDestinationSwitchInfo> | Yes | Callback used to return the page switch event information using a NavDestinationSwitchInfo object. |
Example
// Index.ets
// Example usage of UIObserver.on('navDestinationSwitch', observerOptions, callback)
// UIObserver.off('navDestinationSwitch', observerOptions, callback)
import { uiObserver } from '@kit.ArkUI';
@Component
struct PageOne {
build() {
NavDestination() {
Text("pageOne")
}.title("pageOne")
}
}
// Define callbacks for event listeners.
function callbackFunc(info: uiObserver.NavDestinationSwitchInfo) {
console.info(`testTag navDestinationSwitch from: ${JSON.stringify(info.from)} to: ${JSON.stringify(info.to)}`);
}
@Entry
@Component
struct Index {
private stack: NavPathStack = new NavPathStack();
@Builder
PageBuilder(name: string) {
PageOne()
}
aboutToAppear() {
let obs = this.getUIContext().getUIObserver();
// Register a listener with the specified Navigation component ID.
obs.on('navDestinationSwitch', { navigationId: "myNavId" }, callbackFunc);
}
aboutToDisappear() {
let obs = this.getUIContext().getUIObserver();
// Remove event listeners.
obs.off('navDestinationSwitch', { navigationId: "myNavId" }, callbackFunc);
}
build() {
Column() {
Navigation(this.stack) {
Button("push").onClick(() => {
// Push the PageOne NavDestination onto the navigation stack.
this.stack.pushPath({ name: "pageOne" });
})
}
.id("myNavId")
.title("Navigation")
.navDestination(this.PageBuilder)
}
.width('100%')
.height('100%')
}
}
off('navDestinationSwitch')12+
off(type: 'navDestinationSwitch', observerOptions: observer.NavDestinationSwitchObserverOptions, callback?: Callback<observer.NavDestinationSwitchInfo>): void
Unregisters the listener for Navigation page switch events with configurable observer options.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'navDestinationSwitch', which indicates Navigation page switch events. |
| observerOptions | observer.NavDestinationSwitchObserverOptions | Yes | Observer configuration options. |
| callback | Callback<observer.NavDestinationSwitchInfo> | No | Target listener to unregister. If no parameter is provided, all Navigation listeners are unregistered. |
Example
See the example for on('navDestinationSwitch').
on('willClick')12+
on(type: 'willClick', callback: GestureEventListenerCallback): void
Listens for click event instruction dispatch. The registered callback function is triggered before the event is triggered. The callback type is GestureEventListenerCallback. The screen reader touch exploration mode is supported since API version 20.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'willClick' indicates the dispatch of click event instructions. The registered callback is triggered when the click event is about to occur. |
| callback | GestureEventListenerCallback | Yes | Callback used to return the result. It provides GestureEvent and the target component's FrameNode information. |
Example
// Index.ets
// Example usage of uiObserver.on('willClick', callback)
// uiObserver.off('willClick', callback)
// uiObserver.off('didClick', callback)
// uiObserver.off('didClick', callback)
// Define callbacks for event listeners.
function willClickGestureCallback(event: GestureEvent, node?: FrameNode) {
console.info('Example willClickCallback GestureEvent is called');
}
function willClickCallback(event: ClickEvent, node?: FrameNode) {
console.info('Example willClickCallback ClickEvent is called');
}
function didClickGestureCallback(event: GestureEvent, node?: FrameNode) {
console.info('Example didClickCallback GestureEvent is called');
}
function didClickCallback(event: ClickEvent, node?: FrameNode) {
console.info('Example didClickCallback ClickEvent is called');
}
@Entry
@Component
struct ClickExample {
@State clickCount: number = 0;
@State tapGestureCount: number = 0;
aboutToAppear(): void {
// Add event listeners.
let observer = this.getUIContext().getUIObserver();
observer.on('willClick', willClickGestureCallback);
observer.on('willClick', willClickCallback);
observer.on('didClick', didClickGestureCallback);
observer.on('didClick', didClickCallback);
}
aboutToDisappear(): void {
// Remove event listeners.
let observer = this.getUIContext().getUIObserver();
observer.off('willClick', willClickGestureCallback);
observer.off('willClick', willClickCallback);
// If no callback is specified, all callbacks for this event will be removed.
observer.off('didClick');
}
build() {
Column() {
/**
* onClick and TapGesture are handled in the same way in the backend.
* Therefore, whether onClick or TapGesture is triggered,
* both callback types (GestureEvent and ClickEvent) registered with on('willClick') will be triggered.
* Similarly, both callback types registered with on('didClick') will be triggered.
*/
Column() {
Text('Click Count: ' + this.clickCount)
}
.height(200)
.width(300)
.padding(20)
.border({ width: 3 })
.margin(50)
.onClick((event: ClickEvent) => {
this.clickCount++;
console.info('Example Click event is called');
})
Column() {
Text('TapGesture Count: ' + this.tapGestureCount)
}
.height(200)
.width(300)
.padding(20)
.border({ width: 3 })
.margin(50)
.gesture(TapGesture({ count: 2 }).onAction((event: TapGestureEvent) => {
this.tapGestureCount++;
console.info('Example Click event is called');
}))
}
}
}
off('willClick')12+
off(type: 'willClick', callback?: GestureEventListenerCallback): void
Unregisters the click event command dispatch listener previously registered using on('willClick'). The screen reader touch exploration mode is supported since API version 20.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'willClick' indicates click event instruction dispatch. |
| callback | GestureEventListenerCallback | No | Target listener to unregister. If no parameter is provided, all click event instruction dispatch listeners are unregistered. |
Example
See the example for on('willClick').
on('didClick')12+
on(type: 'didClick', callback: GestureEventListenerCallback): void
Listens for click event instruction dispatch. The registered callback function is triggered after the event is triggered. The callback type is GestureEventListenerCallback. The screen reader touch exploration mode is supported since API version 20.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'didClick' indicates click event instruction dispatch. The registered callback is triggered after the click event occurs. |
| callback | GestureEventListenerCallback | Yes | Callback used to return the result. It provides GestureEvent and the target component's FrameNode information. |
Example
See the example for on('willClick').
off('didClick')12+
off(type: 'didClick', callback?: GestureEventListenerCallback): void
Unregisters the click event command dispatch listener previously registered using on('didClick'). The screen reader touch exploration mode is supported since API version 20.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'didClick' indicates click event instruction dispatch. |
| callback | GestureEventListenerCallback | No | Target listener to unregister. If no parameter is provided, all click event instruction dispatch listeners are unregistered. |
Example
See the example for on('willClick').
on('willClick')12+
on(type: 'willClick', callback: ClickEventListenerCallback): void
Listens for click event instruction dispatch. The registered callback function is triggered before the event is triggered. The callback type is ClickEventListenerCallback. The screen reader touch exploration mode is supported since API version 20.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'willClick' indicates the dispatch of click event instructions. The registered callback is triggered when the click event is about to occur. |
| callback | ClickEventListenerCallback | Yes | Callback used to return the result. It provides ClickEvent and the target component's FrameNode information. |
Example
See the example for on('willClick').
off('willClick')12+
off(type: 'willClick', callback?: ClickEventListenerCallback): void
Unregisters the click event command dispatch listener previously registered using on('willClick'). The screen reader touch exploration mode is supported since API version 20.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'willClick' indicates click event instruction dispatch. |
| callback | ClickEventListenerCallback | No | Target listener to unregister. If no parameter is provided, all click event instruction dispatch listeners are unregistered. |
Example
See the example for on('willClick').
on('didClick')12+
on(type: 'didClick', callback: ClickEventListenerCallback): void
Listens for click event instruction dispatch. The registered callback function is triggered after the event is triggered. The callback type is ClickEventListenerCallback. The screen reader touch exploration mode is supported since API version 20.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'didClick' indicates click event instruction dispatch. The registered callback is triggered after the click event occurs. |
| callback | ClickEventListenerCallback | Yes | Callback used to return the result. It provides ClickEvent and the target component's FrameNode information. |
Example
See the example for on('willClick').
off('didClick')12+
off(type: 'didClick', callback?: ClickEventListenerCallback): void
Unregisters the click event command dispatch listener previously registered using on('didClick'). The screen reader touch exploration mode is supported since API version 20.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value 'didClick' indicates click event instruction dispatch. |
| callback | ClickEventListenerCallback | No | Target listener to unregister. If no parameter is provided, all click event instruction dispatch listeners are unregistered. |
Example
See the example for on('willClick').
on('tabContentUpdate')12+
on(type: 'tabContentUpdate', callback: Callback<observer.TabContentInfo>): void
Listens for TabContent page switch events. Unlike on('tabChange'), this API does not support listening for the initial tab display event when the Tabs component is initialized.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'tabContentUpdate', indicating TabContent page switch events. |
| callback | Callback<observer.TabContentInfo> | Yes | Callback used to return the result. It provides the TabContent page switch event information using the TabContentInfo object. |
Example
// Index.ets
// Example usage of uiObserver.on('tabContentUpdate', callback)
// uiObserver.off('tabContentUpdate', callback)
import { uiObserver } from '@kit.ArkUI';
// Define callbacks for event listeners.
function callbackFunc(info: uiObserver.TabContentInfo) {
console.info('tabContentUpdate', JSON.stringify(info));
}
@Entry
@Component
struct TabsExample {
aboutToAppear(): void {
let observer = this.getUIContext().getUIObserver();
// Add event listeners.
observer.on('tabContentUpdate', callbackFunc);
}
aboutToDisappear(): void {
let observer = this.getUIContext().getUIObserver();
// Remove event listeners.
observer.off('tabContentUpdate', callbackFunc);
}
build() {
Column() {
Tabs() {
TabContent() {
Column().width('100%').height('100%').backgroundColor('#00CB87')
}.tabBar('green').id('tabContentId0')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#007DFF')
}.tabBar('blue').id('tabContentId1')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#FFBF00')
}.tabBar('yellow').id('tabContentId2')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#E67C92')
}.tabBar('pink').id('tabContentId3')
}
.width(360)
.height(296)
.backgroundColor('#F1F3F5')
.id('tabsId')
}.width('100%')
}
}
off('tabContentUpdate')12+
off(type: 'tabContentUpdate', callback?: Callback<observer.TabContentInfo>): void
Unregisters the listener for TabContent page switch events.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'tabContentUpdate', indicating TabContent page switch events. |
| callback | Callback<observer.TabContentInfo> | No | Target listener to unregister. If no parameter is provided, all Tabs listeners are unregistered. |
Example
See the example for on('tabContentUpdate').
on('tabContentUpdate')12+
on(type: 'tabContentUpdate', options: observer.ObserverOptions, callback: Callback<observer.TabContentInfo>): void
Listens for TabContent page switch events using the Tabs component ID. Unlike on('tabChange'), this API does not support listening for the initial tab display event when the Tabs component is initialized.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'tabContentUpdate', indicating TabContent page switch events. |
| options | observer.ObserverOptions | Yes | ID of the target Tabs component. |
| callback | Callback<observer.TabContentInfo> | Yes | Callback used to return the result. It provides the TabContent page switch event information using a TabContentInfo object. |
Example
// Index.ets
// Example usage of uiObserver.on('tabContentUpdate', options, callback)
// uiObserver.off('tabContentUpdate', options, callback)
import { uiObserver } from '@kit.ArkUI';
// Define callbacks for event listeners.
function callbackFunc(info: uiObserver.TabContentInfo) {
console.info('tabContentUpdate', JSON.stringify(info));
}
@Entry
@Component
struct TabsExample {
aboutToAppear(): void {
let observer = this.getUIContext().getUIObserver();
// Register a listener with the specified Tabs component ID.
observer.on('tabContentUpdate', { id: 'tabsId' }, callbackFunc);
}
aboutToDisappear(): void {
let observer = this.getUIContext().getUIObserver();
// Remove event listeners.
observer.off('tabContentUpdate', { id: 'tabsId' }, callbackFunc);
}
build() {
Column() {
Tabs() {
TabContent() {
Column().width('100%').height('100%').backgroundColor('#00CB87')
}.tabBar('green').id('tabContentId0')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#007DFF')
}.tabBar('blue').id('tabContentId1')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#FFBF00')
}.tabBar('yellow').id('tabContentId2')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#E67C92')
}.tabBar('pink').id('tabContentId3')
}
.width(360)
.height(296)
.backgroundColor('#F1F3F5')
.id('tabsId')
}.width('100%')
}
}
off('tabContentUpdate')12+
off(type: 'tabContentUpdate', options: observer.ObserverOptions, callback?: Callback<observer.TabContentInfo>): void
Unregisters the listener for TabContent page switch events using the Tabs component ID.
Atomic service API: This API can be used in atomic services since API version 12.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'tabContentUpdate', indicating TabContent page switch events. |
| options | observer.ObserverOptions | Yes | ID of the target Tabs component. |
| callback | Callback<observer.TabContentInfo> | No | Target listener to unregister. If no parameter is provided, all Tabs listeners are unregistered. |
Example
See the example for on('tabContentUpdate').
on('tabChange')22+
on(type: 'tabChange', callback: Callback<observer.TabContentInfo>): void
Listens for tab switching events of the Tabs component. Multiple Tabs components are supported. Unlike on('tabContentUpdate'), this API supports listening for the initial tab display event when the Tabs component is initialized.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'tabChange', indicating tab switch events of the Tabs component. |
| callback | Callback<observer.TabContentInfo> | Yes | Callback used to return the result. It provides the Tabs component tab switching event information using the TabContentInfo object. |
Example
// Index.ets
// This example demonstrates how to subscribe to tab switching events of Tabs components.
// It simultaneously subscribes to two Tabs components with IDs 'tabsId1' and 'tabsId2'.
// During initialization of both Tabs components, the display events for tab page 0 are listened for, with corresponding tab IDs 'tabContentId0' and 'tabContentId5'.
// After users swipe on the Tabs component with ID 'tabsId1', the system detects the hiding of tab page 0 and the display of tab page 1 with ID 'tabContentId1'.
import { uiObserver } from '@kit.ArkUI';
// Define callbacks for event listeners.
function callbackFunc(info: uiObserver.TabContentInfo) {
console.info('tabChange', JSON.stringify(info));
}
@Entry
@Component
struct TabsExample {
aboutToAppear(): void {
let observer = this.getUIContext().getUIObserver();
// Add event listeners.
observer.on('tabChange', callbackFunc);
}
aboutToDisappear(): void {
let observer = this.getUIContext().getUIObserver();
// Remove event listeners.
observer.off('tabChange', callbackFunc);
}
build() {
Column() {
Tabs() {
TabContent() {
Column().width('100%').height('100%').backgroundColor('#00CB87')
}.tabBar('green').id('tabContentId0')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#007DFF')
}.tabBar('blue').id('tabContentId1')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#FFBF00')
}.tabBar('yellow').id('tabContentId2')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#E67C92')
}.tabBar('pink').id('tabContentId3')
}
.width(360)
.height(296)
.backgroundColor('#F1F3F5')
.id('tabsId1')
Tabs() {
TabContent() {
Column().width('100%').height('100%').backgroundColor('#00CB87')
}.tabBar('green').id('tabContentId5')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#007DFF')
}.tabBar('blue').id('tabContentId6')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#FFBF00')
}.tabBar('yellow').id('tabContentId7')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#E67C92')
}.tabBar('pink').id('tabContentId8')
}
.width(360)
.height(296)
.backgroundColor('#F1F3F5')
.id('tabsId2')
}.width('100%')
}
}
off('tabChange')22+
off(type: 'tabChange', callback?: Callback<observer.TabContentInfo>): void
Unregisters the listener for tab switching events of all Tabs components.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'tabChange', indicating tab switch events of the Tabs component. |
| callback | Callback<observer.TabContentInfo> | No | Target listener to unregister. If no parameter is provided, all listeners registered using the on('tabChange') API are unregistered. Default value: undefined. |
Example
See the example for on('tabChange').
on('tabChange')22+
on(type: 'tabChange', config: observer.ObserverOptions, callback: Callback<observer.TabContentInfo>): void
Listens for tab switching events of the specified Tabs component. Unlike on('tabContentUpdate'), this API supports listening for the initial tab display event when the Tabs component is initialized.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'tabChange', indicating tab switch events of the Tabs component. |
| config | observer.ObserverOptions | Yes | ID of the target Tabs component. |
| callback | Callback<observer.TabContentInfo> | Yes | Callback used to return the result. It provides the Tabs component tab switching event information using the TabContentInfo object. |
Example
// Index.ets
// This example demonstrates how to subscribe to tab change events of the Tabs component with ID 'tabsId'.
// During initialization of the Tabs component, the display events for tab page 0 are listened for, with the corresponding tab ID 'tabContentId0'. After users swipe on the Tabs component, the system detects the hiding of tab page 0 and the display of tab page 1 with ID 'tabContentId1'.
import { uiObserver } from '@kit.ArkUI';
// Define callbacks for event listeners.
function callbackFunc(info: uiObserver.TabContentInfo) {
console.info('tabChange', JSON.stringify(info));
}
@Entry
@Component
struct TabsExample {
aboutToAppear(): void {
let observer = this.getUIContext().getUIObserver();
// Register a listener with the specified Tabs component ID.
observer.on('tabChange', { id: 'tabsId' }, callbackFunc);
}
aboutToDisappear(): void {
let observer = this.getUIContext().getUIObserver();
// Remove event listeners.
observer.off('tabChange', { id: 'tabsId' }, callbackFunc);
}
build() {
Column() {
Tabs() {
TabContent() {
Column().width('100%').height('100%').backgroundColor('#00CB87')
}.tabBar('green').id('tabContentId0')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#007DFF')
}.tabBar('blue').id('tabContentId1')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#FFBF00')
}.tabBar('yellow').id('tabContentId2')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#E67C92')
}.tabBar('pink').id('tabContentId3')
}
.width(360)
.height(296)
.backgroundColor('#F1F3F5')
.id('tabsId')
Tabs() {
TabContent() {
Column().width('100%').height('100%').backgroundColor('#00CB87')
}.tabBar('green').id('tabContentId5')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#007DFF')
}.tabBar('blue').id('tabContentId6')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#FFBF00')
}.tabBar('yellow').id('tabContentId7')
TabContent() {
Column().width('100%').height('100%').backgroundColor('#E67C92')
}.tabBar('pink').id('tabContentId8')
}
.width(360)
.height(296)
.backgroundColor('#F1F3F5')
}.width('100%')
}
}
off('tabChange')22+
off(type: 'tabChange', config: observer.ObserverOptions, callback?: Callback<observer.TabContentInfo>): void
Unregisters the listener for tab switching events of the specified Tabs component.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'tabChange', indicating tab switch events of the Tabs component. |
| config | observer.ObserverOptions | Yes | ID of the target Tabs component. |
| callback | Callback<observer.TabContentInfo> | No | Target listener to unregister. If no parameter is provided, all listeners registered for the Tabs component specified by config are unregistered. Default value: undefined. |
Example
See the example for on('tabChange').
on('textChange')22+
on(type: 'textChange', callback: Callback<observer.TextChangeEventInfo>): void
Listens globally for text input field changes events.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'textChange', indicating text input field changes events. |
| callback | Callback<observer.TextChangeEventInfo> | Yes | Callback used to return the text change information. |
Example
import { UIObserver } from '@kit.ArkUI';
@Entry
@Component
struct TextUiObserver {
observer: UIObserver = this.getUIContext().getUIObserver();
build() {
Column() {
TextArea({ text: "Hello World TextArea" })
.width(336)
.height(56)
.margin({bottom:5})
.backgroundColor('#FFFFFF')
.id("TestId1")
TextInput({ text: "Hello World TextInput" })
.width(336)
.height(56)
.margin({bottom:5})
.backgroundColor('#FFFFFF')
.id("TestId2")
Search({ value: "Hello World Search" })
.width(336)
.height(56)
.margin({bottom:5})
.backgroundColor('#FFFFFF')
.id("TestId3")
Row() {
// Enable global listening.
Button('UIObserver on')
.onClick(() => {
this.observer.on('textChange', (info) => {
console.info('textChangeInfo', JSON.stringify(info));
});
})
// Disable global listening.
Button('UIObserver off')
.onClick(() => {
this.observer.off('textChange');
})
}.margin({bottom:5})
// Enable and disable listening for a specific ID.
Row() {
Button('UIObserver TestId1 on')
.onClick(() => {
this.observer.on('textChange', { id: "TestId1" }, (info) => {
console.info('textChangeInfo', JSON.stringify(info));
});
})
Button('UIObserver TestId1 off')
.onClick(() => {
this.observer.off('textChange', { id: "TestId1" });
})
}.margin({bottom:5})
Row() {
Button('UIObserver TestId2 on')
.onClick(() => {
this.observer.on('textChange', { id: "TestId2" }, (info) => {
console.info('textChangeInfo', JSON.stringify(info));
});
})
Button('UIObserver TestId2 off')
.onClick(() => {
this.observer.off('textChange', { id: "TestId2" });
})
}.margin({bottom:5})
Row() {
Button('UIObserver TestId3 on')
.onClick(() => {
this.observer.on('textChange', { id: "TestId3" }, (info) => {
console.info('textChangeInfo', JSON.stringify(info));
});
})
Button('UIObserver TestId3 off')
.onClick(() => {
this.observer.off('textChange', { id: "TestId3" });
})
}.margin({bottom:5})
}.width('100%').height('100%').backgroundColor('#F1F3F5')
}
}
off('textChange')22+
off(type: 'textChange', callback?: Callback<observer.TextChangeEventInfo>): void
Unregisters the global listener for text input field changes events.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'textChange', indicating text input field changes events. |
| callback | Callback<observer.TextChangeEventInfo> | No | Target listener to unregister. If no parameter is provided, all listeners registered for text input field changes events are unregistered. |
Example
For details, see on('textChange').
on('textChange')22+
on(type: 'textChange', identity: observer.ObserverOptions, callback:Callback<observer.TextChangeEventInfo>): void
Listens on the text input component with the specified ID.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'textChange', indicating text input field changes events. |
| identity | observer.ObserverOptions | Yes | ID of the text input component to be listened on. |
| callback | Callback<observer.TextChangeEventInfo> | Yes | Callback used to return the text change information. |
Example
For details, see on('textChange').
off('textChange')22+
off(type: 'textChange', identity: observer.ObserverOptions, callback?: Callback<observer.TextChangeEventInfo>): void
Disables the listener for the text input component with the specified ID.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'textChange', indicating text input field changes events. |
| identity | observer.ObserverOptions | Yes | ID of the text input component to be listened on. |
| callback | Callback<observer.TextChangeEventInfo> | No | Target listener to unregister. If no parameter is passed, all listeners for the text input component with the specified IDs are canceled. |
Example
For details, see on('textChange').
on('beforePanStart')19+
on(type: 'beforePanStart', callback: PanListenerCallback): void
Listens for pan gesture onActionStart pre-execution events, executing the callback before the actual onActionStart event. It works for finger swiping, mouse dragging, mouse wheel scrolling, and touchpad movements, but not for screen reader touch mode.
Atomic service API: This API can be used in atomic services since API version 19.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'beforePanStart', indicating command dispatch before the execution of the pan gesture onActionStart event. The registered callback is triggered before onActionStart is executed. |
| callback | PanListenerCallback | Yes | Callback used to return the result. It provides GestureEvent, GestureRecognizer, and the target component's FrameNode information. |
Example
// Index.ets
// Example usage of uiObserver.on('beforePanStart', callback)
// uiObserver.off('beforePanStart', callback)
// uiObserver.on('afterPanStart', callback)
// uiObserver.off('afterPanStart', callback)
// uiObserver.on('beforePanEnd', callback)
// uiObserver.off('beforePanEnd', callback)
// uiObserver.on('afterPanEnd', callback)
// uiObserver.off('afterPanEnd', callback)
// Used in page components.
let TEST_TAG: string = 'node';
// Define callbacks for event listeners.
function callbackFunc() {
console.info('on == beforePanStart');
}
function afterPanCallBack() {
console.info('on == afterPanStart');
}
function beforeEndCallBack() {
console.info('on == beforeEnd');
}
function afterEndCallBack() {
console.info('on == afterEnd');
}
function beforeStartCallBack() {
console.info('on == beforeStartCallBack');
}
function panGestureCallBack(event: GestureEvent, current: GestureRecognizer, node?: FrameNode) {
TEST_TAG = 'panGestureEvent';
console.info('===' + TEST_TAG + '=== event.repeat is ' + event.repeat);
console.info('===' + TEST_TAG + '=== event target is ' + event.target.id);
TEST_TAG = 'panGestureCurrent';
console.info('===' + TEST_TAG + '=== current.getTag() is ' + current.getTag());
TEST_TAG = 'panGestureNode';
console.info('===' + TEST_TAG + '=== node?.getId() is ' + node?.getId());
}
@Entry
@Component
struct PanExample {
@State offsetX: number = 0;
@State offsetY: number = 0;
@State positionX: number = 0;
@State positionY: number = 0;
private panOption: PanGestureOptions = new PanGestureOptions({direction: PanDirection.All });
aboutToAppear(): void {
let observer = this.getUIContext().getUIObserver();
// Add event listeners.
observer.on('beforePanStart', callbackFunc);
observer.on('beforePanStart', panGestureCallBack);
observer.on('beforePanStart', beforeStartCallBack);
observer.on('afterPanStart', afterPanCallBack);
observer.on('beforePanEnd', beforeEndCallBack);
observer.on('afterPanEnd', afterEndCallBack);
}
aboutToDisappear(): void {
let observer = this.getUIContext().getUIObserver();
// Remove event listeners.
observer.off('beforePanStart', callbackFunc);
observer.off('beforePanStart');
observer.off('afterPanStart', afterPanCallBack);
observer.off('beforePanEnd');
observer.off('afterPanEnd');
}
build() {
Column(){
Column(){
Text('PanGesture :\nX: ' + this.offsetX + '\n' + 'Y: ' + this.offsetY)
}
.height(200)
.width(300)
.padding(20)
.border({ width: 3 })
.margin(50)
.translate({ x: this.offsetX, y: this.offsetY, z: 0 })
.id('columnOuter')
.gesture(
PanGesture(this.panOption)
.onActionStart((event: GestureEvent) => {
console.info('Pan start');
})
.onActionUpdate((event: GestureEvent) => {
if (event) {
this.offsetX = this.positionX + event.offsetX;
this.offsetY = this.positionY + event.offsetY;
}
})
.onActionEnd((event: GestureEvent) => {
this.positionX = this.offsetX;
this.positionY = this.offsetY;
console.info('Pan end');
}))
}
}
}
off('beforePanStart')19+
off(type: 'beforePanStart', callback?: PanListenerCallback): void
Unregisters the listener for pan gesture onActionStart pre-execution events, canceling callbacks registered via on('beforePanStart').
Atomic service API: This API can be used in atomic services since API version 19.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'beforePanStart', indicating command dispatch before the execution of the pan gesture onActionStart event. |
| callback | PanListenerCallback | No | Target listener to unregister. If no parameter is provided, all callback listeners for command dispatch before the execution of the pan gesture onActionStart event will be removed. |
Example
See the example for on('beforePanStart').
on('afterPanStart')19+
on(type: 'afterPanStart', callback: PanListenerCallback): void
Listens for pan gesture onActionStart post-execution events, executing the callback after the actual onActionStart event. It works for finger swiping, mouse dragging, mouse wheel scrolling, and touchpad movements, but not for screen reader touch mode.
Atomic service API: This API can be used in atomic services since API version 19.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'afterPanStart', indicating command dispatch after the execution of the pan gesture onActionStart event. The registered callback is triggered after onActionStart is executed. |
| callback | PanListenerCallback | Yes | Callback used to return the result. It provides GestureEvent, GestureRecognizer, and the target component's FrameNode information. |
Example
See the example for on('beforePanStart').
off('afterPanStart')19+
off(type: 'afterPanStart', callback?: PanListenerCallback): void
Unregisters the listener for pan gesture onActionStart post-execution events, canceling callbacks registered via on('afterPanStart').
Atomic service API: This API can be used in atomic services since API version 19.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'afterPanStart', indicating command dispatch after the execution of the pan gesture onActionStart event. |
| callback | PanListenerCallback | No | Target listener to unregister. If no parameter is provided, all callback listeners for command dispatch after the execution of the pan gesture onActionStart event will be removed. |
Example
See the example for on('beforePanStart').
on('beforePanEnd')19+
on(type: 'beforePanEnd', callback: PanListenerCallback): void
Listens for pan gesture onActionEnd pre-execution events, executing the callback before the actual onActionEnd event. It works for finger swiping, mouse dragging, mouse wheel scrolling, and touchpad movements, but not for screen reader touch mode.
Atomic service API: This API can be used in atomic services since API version 19.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'beforePanEnd', indicating command dispatch before the execution of the pan gesture onActionEnd event. The registered callback is triggered before onActionEnd is executed. |
| callback | PanListenerCallback | Yes | Callback used to return the result. It provides GestureEvent, GestureRecognizer, and the target component's FrameNode information. |
Example
See the example for on('beforePanStart').
off('beforePanEnd')19+
off(type: 'beforePanEnd', callback?: PanListenerCallback): void
Unregisters the listener for pan gesture onActionEnd pre-execution events, canceling callbacks registered via on('beforePanEnd').
Atomic service API: This API can be used in atomic services since API version 19.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'beforePanEnd', indicating command dispatch before the execution of the pan gesture onActionEnd event. |
| callback | PanListenerCallback | No | Target listener to unregister. If no parameter is provided, all callback listeners for command dispatch before the execution of the pan gesture onActionEnd event will be removed. |
Example
See the example for on('beforePanStart').
on('afterPanEnd')19+
on(type: 'afterPanEnd', callback: PanListenerCallback): void
Listens for pan gesture onActionEnd post-execution events, executing the callback after the actual onActionEnd event. It works for finger swiping, mouse dragging, mouse wheel scrolling, and touchpad movements, but not for screen reader touch mode.
Atomic service API: This API can be used in atomic services since API version 19.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'beforePanEnd', indicating command dispatch after the execution of the pan gesture onActionEnd event. The registered callback is triggered after onActionEnd is executed. |
| callback | PanListenerCallback | Yes | Callback used to return the result. It provides GestureEvent, GestureRecognizer, and the target component's FrameNode information. |
Example
See the example for on('beforePanStart').
off('afterPanEnd')19+
off(type: 'afterPanEnd', callback?: PanListenerCallback): void
Unregisters the listener for pan gesture onActionEnd post-execution events, canceling callbacks registered via on('afterPanEnd').
Atomic service API: This API can be used in atomic services since API version 19.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'afterPanEnd', indicating command dispatch after the execution of the pan gesture onActionEnd event. |
| callback | PanListenerCallback | No | Target listener to unregister. If no parameter is provided, all callback listeners for command dispatch after the execution of the pan gesture onActionEnd event will be removed. |
Example
See the example for on('beforePanStart').
on('nodeRenderState')20+
on(type: 'nodeRenderState', nodeIdentity: NodeIdentity, callback: NodeRenderStateChangeCallback): void
Registers a callback to be invoked when the rendering state of a specific node changes. This callback is executed immediately once upon successful registration.
Be mindful of node quantity limitations. For performance reasons, registering too many nodes within a single UI instance will throw an exception.
Typically, a RENDER_OUT notification is received when a component moves off-screen. However, in certain scenarios, a RENDER_OUT notification might not be triggered even if a component has moved off-screen. For example, components with caching capabilities like Swiper will not trigger RENDER_OUT notifications even when the isShown parameter in the cachedCount attribute is set to true.
Atomic service API: This API can be used in atomic services since API version 20.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'nodeRenderState', indicating rendering state changes. |
| nodeIdentity | NodeIdentity | Yes | Node ID. |
| callback | NodeRenderStateChangeCallback | Yes | Callback used to return the result. It provides the NodeRenderState of the node rendering state change event and the component's FrameNode. |
Error codes
For details about the error codes, see Render State Listening Error Codes.
| ID | Error Message |
|---|---|
| 161001 | The count of nodes monitoring render state is over the limitation. |
Example
This example demonstrates how to add and remove listeners for a target component. When the user swipes left, the target component disappears from the screen, triggering a RENDER_OUT notification. When the user swipes right, the component reappears on the screen, triggering a RENDER_IN notification.
// Index.ets
// Example usage of uiObserver.on('nodeRenderState', nodeIdentity, callback)
// uiObserver.off('nodeRenderState', nodeIdentity, callback)
// Used in page components.
import { NodeRenderState } from '@kit.ArkUI';
@Entry
@Component
struct Index {
@State fontColor: string = '#182431';
@State selectedFontColor: string = '#007DFF';
@State currentIndex: number = 0;
@State selectedIndex: number = 0;
@State notice: string = "";
private controller: TabsController = new TabsController();
@Builder
tabBuilder(index: number, name: string) {
Column() {
Text(name)
.fontColor(this.selectedIndex === index ? this.selectedFontColor : this.fontColor)
.fontSize(16)
.fontWeight(this.selectedIndex === index ? 500 : 400)
.lineHeight(22)
.margin({ top: 17, bottom: 7 })
Divider()
.strokeWidth(2)
.color('#007DFF')
.opacity(this.selectedIndex === index ? 1 : 0)
}.width('100%')
}
build() {
Column() {
Tabs({ barPosition: BarPosition.Start, index: this.currentIndex, controller: this.controller }) {
TabContent() {
Column() {
Column() {
Button("Listened Node").margin({ top: 5 }).id("button_1")
Button("Add Listener").margin({ top: 5 }).onClick(() => {
let node: FrameNode|null = this.getUIContext().getFrameNodeById("button_1");
if (node) {
let observer = this.getUIContext().getUIObserver();
// Add event listeners.
observer.on("nodeRenderState", node?.getUniqueId(), (state: NodeRenderState, node?: FrameNode) => {
// Update notification content based on node state changes.
if (state === 0) {
this.notice = "RENDER_IN";
} else {
this.notice = "RENDER_OUT";
}
console.info("Node state changed. Current state: ", state);
})
}
})
Button("Remove Listener").margin({ top: 5 }).onClick(() => {
let node: FrameNode|null = this.getUIContext().getFrameNodeById("button_1");
if (node) {
let observer = this.getUIContext().getUIObserver();
// Unregister the listener. Omitting the callback parameter removes all registered listeners.
observer.off("nodeRenderState", node?.getUniqueId());
}
this.notice = "";
})
}
}.width('100%').height('100%').backgroundColor('#00CB87')
}.tabBar(this.tabBuilder(0, 'green'))
TabContent() {
Column().width('100%').height('100%').backgroundColor('#007DFF')
}.tabBar(this.tabBuilder(1, 'blue'))
TabContent() {
Column().width('100%').height('100%').backgroundColor('#FFBF00')
}.tabBar(this.tabBuilder(2, 'yellow'))
TabContent() {
Column().width('100%').height('100%').backgroundColor('#E67C92')
}.tabBar(this.tabBuilder(3, 'pink'))
}
.vertical(false)
.barMode(BarMode.Fixed)
.barWidth(360)
.barHeight(56)
.animationDuration(400)
.onChange((index: number) => {
this.currentIndex = index;
this.selectedIndex = index;
})
.onAnimationStart((index: number, targetIndex: number, event: TabsAnimationEvent) => {
if (index === targetIndex) {
return;
}
this.selectedIndex = targetIndex;
})
.width(360)
.height(296)
.margin({ top: 52 })
.backgroundColor('#F1F3F5')
Text(`Notification received: ${this.notice}`)
.fontSize(20)
.margin(10)
}.width('100%')
}
}
off('nodeRenderState')20+
off(type: 'nodeRenderState', nodeIdentity: NodeIdentity, callback?: NodeRenderStateChangeCallback): void
Unregisters the callback for listening for node rendering state changes.
Atomic service API: This API can be used in atomic services since API version 20.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'nodeRenderState'. |
| nodeIdentity | NodeIdentity | Yes | Node ID. |
| callback | NodeRenderStateChangeCallback | No | Target listener to unregister. If no parameter is provided, all node rendering state change listeners are unregistered. |
Example
See the example for on('nodeRenderState').
addGlobalGestureListener20+
addGlobalGestureListener(type: GestureListenerType, option: GestureObserverConfigs, callback: GestureListenerCallback): void
Registers a callback to listen for gesture triggering information.
Atomic service API: This API can be used in atomic services since API version 20.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | GestureListenerType | Yes | Type of gesture to listen for. |
| option | GestureObserverConfigs | Yes | Configuration options for binding the global listener. |
| callback | GestureListenerCallback | Yes | Callback triggered when the gesture state updates. |
Example
This example uses global gesture listeners to monitor the trigger status of three independent areas (Tap, Pan, and LongPress) in real time, records the trigger count and last operation information for each gesture, and automatically manages the registration and unregistration of listeners during the component's lifecycle.
// Index.ets
// Example usage of uiObserver.addGlobalGestureListener(type, option, callback)
// uiObserver.removeGlobalGestureListener(type, callback)
import { GestureListenerType, GestureActionPhase, GestureTriggerInfo, GestureListenerCallback } from '@kit.ArkUI';
@Entry
@Component
struct Index {
@State message: string = 'Global Gesture Listening';
@State tapCount: number = 0;
@State panCount: number = 0;
@State longPressCount: number = 0;
@State lastAction: string = 'None';
@State lastArea: string = 'None';
// Store listener callback references.
private tapCallback?: GestureListenerCallback;
private panCallback?: GestureListenerCallback;
private longPressCallback?: GestureListenerCallback;
// Enable global listeners.
aboutToAppear() {
this.addGlobalListeners();
}
// Disable global listeners.
aboutToDisappear() {
this.removeGlobalListeners();
}
private addGlobalListeners() {
const observer = this.getUIContext().getUIObserver();
// Tap listener.
this.tapCallback = (info: GestureTriggerInfo) => {
if (info.event?.target?.id === 'tap-area') {
this.tapCount++;
this.lastAction = 'Tap';
this.lastArea = 'Tap area';
}
};
observer.addGlobalGestureListener(
GestureListenerType.TAP,
{ actionPhases: [GestureActionPhase.WILL_START, GestureActionPhase.WILL_END] },
this.tapCallback
);
// Pan listener.
this.panCallback = (info: GestureTriggerInfo) => {
if (info.event?.target?.id === 'pan-area') {
this.panCount++;
this.lastAction = 'Pan';
this.lastArea = 'Pan area';
}
};
observer.addGlobalGestureListener(
GestureListenerType.PAN,
{
actionPhases: [GestureActionPhase.WILL_START, GestureActionPhase.WILL_END]
},
this.panCallback
);
// LongPress listener.
this.longPressCallback = (info: GestureTriggerInfo) => {
if (info.event?.target?.id === 'longpress-area') {
this.longPressCount++;
this.lastAction = 'Long press';
this.lastArea = 'Long press area';
}
};
observer.addGlobalGestureListener(
GestureListenerType.LONG_PRESS,
{
actionPhases: [GestureActionPhase.WILL_START, GestureActionPhase.WILL_END]
},
this.longPressCallback
);
}
private removeGlobalListeners() {
const observer = this.getUIContext().getUIObserver();
if (this.tapCallback) {
observer.removeGlobalGestureListener(0, this.tapCallback);
}
if (this.panCallback) {
observer.removeGlobalGestureListener(2, this.panCallback);
}
if (this.longPressCallback) {
observer.removeGlobalGestureListener(1, this.longPressCallback);
}
}
build() {
Column() {
// Gesture data statistics panel.
Row({ space: 30 }) {
Column() {
Text('Tap count:').fontSize(16)
Text(`${this.tapCount}`).fontSize(24).fontColor('#FF6B81')
}
Column() {
Text('Pan count:').fontSize(16)
Text(`${this.panCount}`).fontSize(24).fontColor('#7BED9F')
}
Column() {
Text('Long press count:').fontSize(16)
Text(`${this.longPressCount}`).fontSize(24).fontColor('#70A1FF')
}
}
.margin(10)
Text(`Last action: ${this.lastAction} (${this.lastArea})`)
.fontSize(18)
.margin(10)
// Gesture areas.
Row() {
Text('Tap area').fontSize(18)
}
.id('tap-area')
.width('90%')
.height(120)
.margin(10)
.border({ width: 2, color: '#FF6B81' })
.justifyContent(FlexAlign.Center)
.gesture(TapGesture().onAction((event: GestureEvent)=>{
// Implementation details.
}))
Row() {
Text('Pan area').fontSize(18)
}
.id('pan-area')
.width('90%')
.height(120)
.margin(10)
.border({ width: 2, color: '#7BED9F' })
.justifyContent(FlexAlign.Center)
.gesture(
PanGesture()
.onActionStart((event: GestureEvent) => {
// Implementation details.
})
.onActionEnd((event: GestureEvent) => {
// Implementation details.
})
)
Row() {
Text('LongPress area').fontSize(18)
}
.id('longpress-area')
.width('90%')
.height(120)
.margin(10)
.border({ width: 2, color: '#70A1FF' })
.justifyContent(FlexAlign.Center)
.gesture(
LongPressGesture()
.onAction((event: GestureEvent)=>{
// Implementation details.
})
.onActionEnd((event: GestureEvent) => {
// Implementation details.
})
)
}
.width('100%')
.height('100%')
}
}
removeGlobalGestureListener20+
removeGlobalGestureListener(type: GestureListenerType, callback?: GestureListenerCallback): void
Unregisters the specified global gesture listener.
Atomic service API: This API can be used in atomic services since API version 20.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | GestureListenerType | Yes | Event type. |
| callback | GestureListenerCallback | No | Callback to unregister. If this parameter is not specified, this API unregisters all callbacks for this gesture type. |
Example
See the example for the addGlobalGestureListener API .
on('windowSizeLayoutBreakpointChange')22+
on(type: 'windowSizeLayoutBreakpointChange', callback: Callback<observer.WindowSizeLayoutBreakpointInfo>): void
Registers a callback for window size layout breakpoint changes. This enables adaptive UI layout adjustments based on window size variations. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'windowSizeLayoutBreakpointChange', indicating window size layout breakpoint changes. |
| callback | Callback<observer.WindowSizeLayoutBreakpointInfo> | Yes | Callback used to return the result. It provides window width and height layout breakpoint enumerations using a WindowSizeLayoutBreakpointinfo object. |
Example
This example demonstrates how to register and unregister window size layout breakpoint change listeners.
import { uiObserver, window } from '@kit.ArkUI';
import { common } from '@kit.AbilityKit';
@Entry
@Component
struct Index {
private changeOrientation(isLandscape: boolean) {
let context = this.getUIContext().getHostContext() as common.UIAbilityContext;
window.getLastWindow(context).then((lastWindow) => {
lastWindow.setPreferredOrientation(isLandscape ? window.Orientation.LANDSCAPE : window.Orientation.PORTRAIT)
});
}
@State message: string = '';
@State widthBreakpoint: WidthBreakpoint = WidthBreakpoint.WIDTH_SM;
@State heightBreakpoint: HeightBreakpoint = HeightBreakpoint.HEIGHT_SM;
winSizeLayoutBreakpointCallback = (info: uiObserver.WindowSizeLayoutBreakpointInfo) => {
this.widthBreakpoint = info.widthBreakpoint;
this.heightBreakpoint = info.heightBreakpoint;
this.message = 'widthBpt:' + this.widthBreakpoint.toString() + 'heightBpt:' + this.heightBreakpoint.toString();
}
build() {
Column() {
Text(this.message)
Button('Register Window Size Breakpoint Change Listener')
.onClick(() => {
this.getUIContext()
.getUIObserver()
.on('windowSizeLayoutBreakpointChange', this.winSizeLayoutBreakpointCallback);
})
Button('Unregister Window Size Breakpoint Change Listener')
.onClick(() => {
this.getUIContext()
.getUIObserver()
.off('windowSizeLayoutBreakpointChange', this.winSizeLayoutBreakpointCallback);
})
Button("Portrait").onClick(() => {
this.changeOrientation(false)
})
Button("Landscape").onClick(() => {
this.changeOrientation(true)
})
}
}
}
off('windowSizeLayoutBreakpointChange')22+
off(type: 'windowSizeLayoutBreakpointChange', callback?: Callback<observer.WindowSizeLayoutBreakpointInfo>): void
Unregisters previously registered window size layout breakpoint change listeners. If no callback is specified, all listeners for the current UI context are removed. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| type | string | Yes | Event type. The value is fixed at 'windowSizeLayoutBreakpointChange', indicating window size layout breakpoint changes. |
| callback | Callback<observer.WindowSizeLayoutBreakpointInfo> | No | Target listener to unregister. If no parameter is provided, all window size layout breakpoint change listeners for the current UIContext are removed. |
Example
See the example for on('windowSizeLayoutBreakpointChange').
onSwiperContentUpdate22+
onSwiperContentUpdate(callback: Callback<SwiperContentInfo>): void
Listens for content switching events of the Swiper component. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| callback | Callback<SwiperContentInfo> | Yes | Callback used to return the result. It provides the Swiper content switching information using a SwiperContentInfo object. |
Example
// Index.ets
import { SwiperContentInfo } from '@kit.ArkUI';
// Define callbacks for event listeners.
function callbackFunc(info: SwiperContentInfo) {
console.info('swiperContentUpdate', JSON.stringify(info));
}
@Entry
@Component
struct SwiperExample {
private swiperController: SwiperController = new SwiperController();
aboutToAppear(): void {
// Listen for 'swiperContentUpdate' events.
this.getUIContext().getUIObserver().onSwiperContentUpdate(callbackFunc);
}
aboutToDisappear(): void {
// Unregister the listener for 'swiperContentUpdate' events.
this.getUIContext().getUIObserver().offSwiperContentUpdate(callbackFunc);
}
build() {
Column({ space: 5 }) {
Swiper(this.swiperController) {
Column() {
Text("SwiperItem1")
}.width('100%').height('100%').backgroundColor('#00CB87')
Column() {
Text("SwiperItem2")
}.width('100%').height('100%').backgroundColor('#007DFF')
Column() {
Text("SwiperItem3")
}.width('100%').height('100%').backgroundColor('#FFBF00')
Column() {
Text("SwiperItem4")
}.width('100%').height('100%').backgroundColor('#E67C92')
}
.width(360)
.height(300)
}.width('100%')
}
}
offSwiperContentUpdate22+
offSwiperContentUpdate(callback?: Callback<SwiperContentInfo>): void
Unregister the listener for content switching events of the Swiper component.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| callback | Callback<SwiperContentInfo> | No | Target listener to unregister. If no parameter is provided, all listeners for the Swiper component are unregistered. |
Example
See the example for the onSwiperContentUpdate API.
onSwiperContentUpdate22+
onSwiperContentUpdate(config: observer.ObserverOptions, callback: Callback<SwiperContentInfo>): void
Listens for content switching events of a specific Swiper component identified by its ID. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| config | observer.ObserverOptions | Yes | Information about the target Swiper component. |
| callback | Callback<SwiperContentInfo> | Yes | Callback used to return the result. It provides the Swiper content switching information using a SwiperContentInfo object. |
Example
// Index.ets
import { SwiperContentInfo } from '@kit.ArkUI';
// Define callbacks for event listeners.
function callbackFunc(info: SwiperContentInfo) {
console.info('swiperContentUpdate', JSON.stringify(info));
}
@Entry
@Component
struct SwiperExample {
private swiperController: SwiperController = new SwiperController();
aboutToAppear(): void {
// Listen for 'swiperContentUpdate' events for the component with the specified ID.
this.getUIContext().getUIObserver().onSwiperContentUpdate({ id: 'swiperId' }, callbackFunc);
}
aboutToDisappear(): void {
// Unregister the listener for 'swiperContentUpdate' events for the component with the specified ID.
this.getUIContext().getUIObserver().offSwiperContentUpdate({ id: 'swiperId' }, callbackFunc);
}
build() {
Column({ space: 5 }) {
Swiper(this.swiperController) {
Column() {
Text("SwiperItem1")
}.width('100%').height('100%').backgroundColor('#00CB87')
Column() {
Text("SwiperItem2")
}.width('100%').height('100%').backgroundColor('#007DFF')
Column() {
Text("SwiperItem3")
}.width('100%').height('100%').backgroundColor('#FFBF00')
Column() {
Text("SwiperItem4")
}.width('100%').height('100%').backgroundColor('#E67C92')
}
.id("swiperId")
.width(360)
.height(300)
}.width('100%')
}
}
offSwiperContentUpdate22+
offSwiperContentUpdate(config: observer.ObserverOptions, callback?: Callback<SwiperContentInfo>): void
Unregister the listener for content switching events of a specific Swiper component identified by its ID.
Atomic service API: This API can be used in atomic services since API version 22.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| config | observer.ObserverOptions | Yes | Information about the target Swiper component. |
| callback | Callback<SwiperContentInfo> | No | Target listener to unregister. If no parameter is provided, all listeners for the Swiper component are unregistered. |
Example
See the example for the onSwiperContentUpdate API.
onRouterPageSizeChange23+
onRouterPageSizeChange(callback: Callback<observer.RouterPageInfo>): void
Registers a callback that is triggered when the size of the visible router page changes. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 23.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| callback | Callback<observer.RouterPageInfo> | Yes | Callback used to return the information about the router page. |
Example
import { uiObserver } from '@kit.ArkUI';
function myPageRouterPageSizeCallback(info: uiObserver.RouterPageInfo): void {
console.info(`testTag pageSize changeTo ${(info && info.size) ? JSON.stringify(info.size) : 'NA'}`);
}
@Entry
@Component
struct QueryRouterPageSize {
aboutToAppear(): void {
// You can obtain the page size information by registering a listener.
this.getUIContext().getUIObserver().onRouterPageSizeChange(myPageRouterPageSizeCallback);
}
aboutToDisappear(): void {
this.getUIContext().getUIObserver().offRouterPageSizeChange(myPageRouterPageSizeCallback);
}
build() {
Column() {
Button('querySize').onClick(() => {
// You can also proactively obtain the page size.
let info = this.queryRouterPageInfo();
console.info(`testTag pageSize: ${info && info.size ? JSON.stringify(info.size) : "NA"}`)
})
}
.width('100%')
.height('100%')
}
}
offRouterPageSizeChange23+
offRouterPageSizeChange(callback?: Callback<observer.RouterPageInfo>): void
Removes the listener callback registered using the onRouterPageSizeChange API. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 23.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| callback | Callback<observer.RouterPageInfo> | No | Callback to be removed. If no parameter is passed, all callbacks are removed. |
Example
See the example for the onRouterPageSizeChange API.
onNavDestinationSizeChange23+
onNavDestinationSizeChange(callback: Callback<observer.NavDestinationInfo>): void
Registers a callback that is triggered when the size of the visible navigation destination changes. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 23.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| callback | Callback<observer.NavDestinationInfo> | Yes | Callback used to return navigation destination information. |
Example
import { uiObserver } from '@kit.ArkUI';
@Component
struct PageOneContent {
destSizeCallback(info: uiObserver.NavDestinationInfo): void {
console.info(`testTag destSize changeTo ${(info && info.size) ? JSON.stringify(info.size) : "NA"}`)
}
aboutToAppear(): void {
// You can obtain the size of the navigation destination page by registering a listener.
this.getUIContext().getUIObserver().onNavDestinationSizeChange(this.destSizeCallback);
}
aboutToDisappear(): void {
this.getUIContext().getUIObserver().offNavDestinationSizeChange(this.destSizeCallback);
}
build() {
Column() {
Button('queryDestSize').onClick(() => {
// You can also proactively obtain the size of the navigation destination page.
let info = this.queryNavDestinationInfo();
console.info(`testTag destSize: ${(info && info.size) ? JSON.stringify(info.size) : "NA"}`)
})
}
.width('100%')
.height('100%')
}
}
@Component
struct PageOne {
build() {
NavDestination() {
PageOneContent()
}
.title('pageOne')
}
}
@Entry
@Component
struct QueryNavDestinationSize {
private stack: NavPathStack = new NavPathStack();
aboutToAppear(): void {
this.stack.pushPath({name: 'one'});
}
@Builder
MyPageMap(name: string) {
PageOne()
}
build() {
Navigation(this.stack) {
}
.width('100%')
.height('100%')
.navDestination(this.MyPageMap)
.hideNavBar(true)
}
}
offNavDestinationSizeChange23+
offNavDestinationSizeChange(callback?: Callback<observer.NavDestinationInfo>): void
Removes the listener callback registered using the onNavDestinationSizeChange API. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 23.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| callback | Callback<observer.NavDestinationInfo> | No | Callback to be removed. If no parameter is passed, all callbacks are removed. |
Example
See the example for the onNavDestinationSizeChange API.
onNavDestinationSizeChangeByUniqueId23+
onNavDestinationSizeChangeByUniqueId(navigationUniqueId: number, callback: Callback<observer.NavDestinationInfo>): void
Registers a callback for listening to the size change of a visible NavDestination component that belongs to a specified Navigation component. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 23.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| navigationUniqueId | number | Yes | Unique ID of the Navigation component to which the NavDestination component to be listened belongs, which can be obtained through queryNavigationInfo. |
| callback | Callback<observer.NavDestinationInfo> | Yes | Callback used to return navigation destination information. |
Example
import { uiObserver } from '@kit.ArkUI';
@Component
struct PageOneContent {
private navUniqueId: number = 0;
destSizeCallback(info: uiObserver.NavDestinationInfo): void {
console.info(`testTag destSize changeTo ${(info && info.size) ? JSON.stringify(info.size) : "NA"}`)
}
aboutToAppear(): void {
let navInfo = this.queryNavigationInfo();
if (navInfo && navInfo.uniqueId) {
this.navUniqueId = navInfo.uniqueId;
// You can obtain the size of the navigation destination page by registering a listener.
this.getUIContext().getUIObserver().onNavDestinationSizeChangeByUniqueId(this.navUniqueId, this.destSizeCallback);
}
}
aboutToDisappear(): void {
this.getUIContext().getUIObserver().offNavDestinationSizeChangeByUniqueId(this.navUniqueId, this.destSizeCallback);
}
build() {
Column() {
Button('queryDestSize').onClick(() => {
// You can also proactively obtain the size of the navigation destination page.
let info = this.queryNavDestinationInfo();
console.info(`testTag destSize: ${(info && info.size) ? JSON.stringify(info.size) : "NA"}`)
})
}
.width('100%')
.height('100%')
}
}
@Component
struct PageOne {
build() {
NavDestination() {
PageOneContent()
}
.title('pageOne')
}
}
@Entry
@Component
struct QueryNavDestinationSize {
private stack: NavPathStack = new NavPathStack();
aboutToAppear(): void {
this.stack.pushPath({name: 'one'});
}
@Builder
MyPageMap(name: string) {
PageOne()
}
build() {
Navigation(this.stack) {
}
.width('100%')
.height('100%')
.navDestination(this.MyPageMap)
.hideNavBar(true)
}
}
offNavDestinationSizeChangeByUniqueId23+
offNavDestinationSizeChangeByUniqueId(navigationUniqueId: number, callback?: Callback<observer.NavDestinationInfo>): void
Removes the listener callback registered using the onNavDestinationSizeChangeByUniqueId API. This API uses an asynchronous callback to return the result.
Atomic service API: This API can be used in atomic services since API version 23.
System capability: SystemCapability.ArkUI.ArkUI.Full
Parameters
| Name | Type | Mandatory | Description |
|---|---|---|---|
| navigationUniqueId | number | Yes | Unique ID of the Navigation component to which the NavDestination component to be listened belongs, which can be obtained through queryNavigationInfo. |
| callback | Callback<observer.NavDestinationInfo> | No | Callback to be removed. If no parameter is passed, all callbacks with the same navigationUniqueId setting are removed. |
Example
See the example for the onNavDestinationSizeChangeByUniqueId API.
你可能感兴趣的鸿蒙文章
openharmony 鸿蒙 arkts-apis-uicontext-contextmenucontroller
openharmony 鸿蒙 errorcode-canvas
openharmony 鸿蒙 capi-oh-nativexcomponent-native-xcomponent-oh-nativexcomponent
openharmony 鸿蒙 errorcode-bindSheet
openharmony 鸿蒙 js-apis-arkui-uiExtension-sys
openharmony 鸿蒙 capi-arkui-accessibility-arkui-accessibilityeventinfo
openharmony 鸿蒙 capi-arkui-rendernodeutils
openharmony 鸿蒙 js-apis-arkui-node
openharmony 鸿蒙 capi-native-node-h
openharmony 鸿蒙 capi-arkui-nativemodule-arkui-listitemswipeactionitem
